Sumitomo-Hansen M4 ACC
Hansen M4 ACC
Powerful solution for Air Cooled Condensers
Overview：
· Specifically designed for Air Cooled Condenser (ACC) drives.
· Our 'Dedicated' products offer a cost effective, robust & efficient solution.
· Standard with lantern housing, allowing an alignment-free connection of a motor on the top of the gear unit.
· Available in 6 sizes (20-70 kNm)
Technical Info：
Number of Sizes | 6 |
Housing type | Monoblock housing with lantern housing |
Gears | Helical gears (designed and rated in accordance with AGMA) |
Reduction Ratios | 9:1 to 25:1 and special ratio's upon request |
Nominal output torque | from 20 to 70 kNm |
Input speed | up to 1800 rpm |
Shaft length | upon request |
Lubrication | Pump with integrated lubrication (no outside piping) |
